Conform Single HD Articulating Monitor Arm
Engineered to support heavier all-in-one computer monitors and VESA mounted CPU/monitor combinations, the Conform Heavy Duty will lift up to 40 pounds with ease. Utilizing the same pin connection system as the rest of the series, the Conform Heavy Duty can be used with any Conform base or configured to work with any other Conform Monitor Arm. The exceptionally smooth lifting heavy duty gas spring, coupled with precision bushings, provides years of maintenance-free maneuverability. The Conform Heavy Duty Articulating Arm has been engineered to support over 12,000 cycles and exceeds ANSI/BIFMA X5.5 requirements. TAA Compliant.
Conform Single HD Articulating Features
Benefits
- Enhance performance through ergonomic comfort
- Smooth lifting, maintenance-free gas spring (supports 17–40 lb monitor)
- Expandable, interchangeable components ensure future adaptability
- Designed for fast, easy installation
- Easily route and conceal cables through the integrated wire managers
- Quickly folds down to provide users with maximum desk space
- Available in Silver
Specifications
- Supports monitor 17–40 lb
- Maximum monitor height: 14″ (full range of motion)
- Articulation range: 13.5″
- Forward reach: 22.5″
- Stowed depth: 5.25″
- Monitor : Tilt: +90°/-45°; Pivot: +/-90°; Rotation: +/-90°
- Standard VESA (75 mm & 100 mm)
- Warranty: 10 year
Convert to a dual arm with the Universal Twin Bracket
Preconfigured Conform Single HD Articulating
Conform Single HD Articulating Arm with C-Clamp & Grommet Base
- Convenient top adjusting C-clamp design
- Includes both C-clamp & grommet mounting options
- 180° pivot limiter on lower arm for space constrained environments
- Supports up to 48 lb
Conform Single HD Articulating Arm with 2 Piece C-Clamp & Grommet Base
- Detachable two piece C-clamp design for panel mounted desks
- Includes both C-clamp & grommet mounting options
- 180° pivot limiter on lower arm for space constrained environments
- Supports up to 48 lb
Additional base options available for a-la-carte order or via the Online Store.
Instructions
Certifications
Get Conform Single HD Articulating
To learn more about Conform Single HD Articulating Monitor Arm or to get your project started, contact your local
